Main specifications
Name & Type
Duke II, AHTS, Shoalbuster
Built & Flag
2013, Cyprus
Bollard Pull
80.5 t
Summary
General Information
Type of vessel: AHTS
Call sign: 5BVM3
IMO number: 9677947
Year of build: 2013
Shipyard: Gebr. Kooiman, The Nederlands
Flag: Cyprus
Class: Bureau Veritas 1 HULL MACH, Tug. Unrestricted navigation, AUT UMS, ICE-Class 1a Super
GMDSS: A1, A2, A3
Main Data
Lenght Overall: 34.10m
Beam:11.00m
Depth: 4.25m
Draft: 4.20m
Free Deck Space: 140m2
Deckload: 7 t/m2
Gross Tonnage: 438 t
Nett Tonnage: 131 t
Accommodation: 8 men
Activities
✓ Towing
✓ Anchor Handling
Engines/Propulsion
Main Engines: 2 x Mitsubishi type S12 U MPTK
Output: 2 x 3040 bhp / 2 x2238 kW
Gearboxes: WAF 4566 2205 KW
Propulsion: 2 fixed propellers in shot nozzles
Bow-Thruster: 440 kW
Generators: 2 x Mitsubishi 6D 16-TE2
Capacity: 2 x 106 kW
Hydraillic Set: 1 x Mitsubishi SGR-MPTAW4 635 kW
Speed: 10 knots
Bollard pull: 80.5 t
Towing Equipment
Deck Crane: HEILA, SWL 25 t R7.5;9.8t R16.3
Anchor Handling:
Main drum with wire 1000 m, Ø58 mm,
2nd drum with wire 700 m, Ø58 mm
Towing pins
Push Bow: Rubber Fender
Stern Roller: 6000 x 1000 mm
Tuggerwinch: 2 x 8500kN, wire 40 m, Ø18 mm
Bunker Capacity
Fuel Oil: 302 m3
Fresh Water: 19.6 m3
Durty Oil: 3.8 m3
Luboil: 4.6 m3
Sewage: 15.9 m3
Communication
Immarsat-C: 420985510/420985511
SAT Phone: +357 2303216
E-mail: [email protected]
Cell Phone: +31 6 26 11 56 00
Specification Sheet Duke II
You can download the full specifications of the vessel here.
